Type

GR28-GR33-GR38-GR47-GR55-GR72-GR90

Flange

BKT,SAE-A standard or SAE-B(option)

Connections

GAS or SAE3000/6000 flange

Installation

Free

Shaft rotation

Clockwise viewed at the shaft end

Shaft speed

100 - 3600rpm

Flows

0 - 800L/min(1500rpm)

Outlet pressure

Outlet pressure:continuous:270 bar; Max:300 bar300bar

Inlet pressure

From 0.7 to 2bar（10bar option)

Fluids

Mineral oil HLP and HLVP

Ecologic fluids HETG-HEPG-HEE

HFA oil-water emulsion - oil minimum 5%

HFB water-oil emulsion < 40%

HFC water-glycole - water max 35 to 55%

HFDR phosphate ester

Lubrification high viscosity oil

Special synthetic fluid:MIL-H、SKYDROL;special on request

Viscosity

Recommend： frome 4 to 2000cst

Working temperature

From -20 to +80℃

Ambiente temperature

From -15 to +60℃

Filtration

Inlet: 100µm Outlet:10-25µm

Seal

NBR、FPM、EPDM

Noise level

From 54 to 68 dB(A) at 2750rpm base on IS04412

Pump body

Extruded aluminium alloy,cast iron

Rotors

Hardened steel
